Upgrade your lighting control with the Timeguard Dimax 540 Plus B Theben LED Mini Dimmer (5400130)—the world’s smallest 230V UP dimmer. This ultra-compact dimmer is ideal for residential and commercial installations, providing reliable performance and ease of use. Whether you’re upgrading your lighting system or installing a new one, the Timeguard Dimax 540 Plus B ensures effortless dimming control with enhanced energy efficiency.

Features

• Compact & Versatile – The smallest 230V UP dimmer, perfect for retrofitting behind a standard push button.
• No Neutral Wire Needed – Simplifies installation, making it ideal for new or existing setups.
• Optimised for LEDs & Incandescent Lamps – Prevents flickering and ensures smooth dimming.
• Multiple Control Points – Switch and dim from multiple locations.
• Enhanced Safety Features – Built-in temperature and overcurrent cut-off, plus a short-circuit fuse.
• Smart Memory Function – Saves the most recently set light level for convenience.
• Adjustable Minimum Brightness – Set to 10% by default, but customizable to your preference.

Specifications

• Operating Voltage: 230V AC | Frequency: 50 - 60 Hz
• Installation Type: Flush-mounted | Standby Power Consumption: ~0.34W
• Load Capacities: LED Lamps (2-8W): Up to 150W Incandescent/Halogen Lamps: Up to 150W
• Control Type: Push-button | Max Cable Length: 100m
• Dimensions: Height: 25.5mm, Width: 26.4mm, Depth: 10.4mm
• Operating Temperature: -10°C to 45°C
• Manufacturer’s Guarantee: 3 Years
