Stephen P Wales Eastron SDM210-DR 100A Single Phase MID Approved DIN Rail Meter | SPDEA210
The Eastron SDM210-DR is a 100 Amp, DIN Rail, single phase meter. At only two modules wide, this compact unit can easily fit into consumer units, providing a neat solution for installations where space may be tight. It’s MID approved so suitable for billing applications and highly accurate, certified to Class B. It displays both Energy (kWh), Power (W), Current (I) & Voltage (V) and can be easily read with its white back lit display.
Stephen P Wales Eastron SDM210-DR 100A Single Phase MID Approved DIN Rail Meter | SPDEA210
The Eastron SDM210-DR is a 100 Amp, DIN Rail, single phase meter. At only two modules wide, this compact unit can easily fit into consumer units, providing a neat solution for installations where space may be tight. It’s MID approved so suitable for billing applications and highly accurate, certified to Class B. It displays both Energy (kWh), Power (W), Current (I) & Voltage (V) and can be easily read with its white back lit display.
There are two Energy (kWh) registers, one shows total cumulative consumption, the second can be reset to zero, perfect for billing applications where the meter is read periodically. It also features a passive pulse output, where the constant is 1000 imp/kWh.
